Teltonika RUTM09 4G LTE Router
Your price incl. VAT (20.0%)
234.91 EUR
✅ In Stock < 10 Бр.
Planned Delivery Date by Courier to you 20-11-2024
Product description
The RUTM09 is a wireless 4G LTE router developed for high-cellular-speed applications. It comes with Cat 6 and dual SIM capabilities, enabling the device to support speeds of up to 300 Mbps and functions like carrier aggregation and failover. Additionally, the RUTM09 comes with four Gigabit RJ45 ports and includes GNSS, enabling GPS tracking for precise location detection. These features make the RUTM09 an exceptional choice for ensuring non-interruptible network connectivity for mobile applications or those requiring tracking.
Package contents
- Device
- 18 W PSU
- 2x Mobile antennas (swivel, SMA male)
- 1x GNSS antenna (adhesive, SMA male, 3 m cable)
- Ethernet cable (1.5 m)
- SIM Adapter kit
- QSG (Quick Start Guide)
- Packaging box
Download
Technical parameters
LAN ports
Power over Ethernet
9 .. 50V DC
VPN support
Yes
Supported VPN
GRE, IPSec, L2TP, OpenVPN, PPTP, WireGuard, ZeroTier, Tinc
Management
SSH, Web management
Wireless frequency
3G (GSM), 4G (GSM), LTE
Type of antenna
Detachable
RF connectors
(2) RSMA female, (1) SMA female
Purpose
Indoor
Integrated 4G/LTE radio part
Yes
Power type
4-pin automotive, PoE
4G/LTE bands support
(1) 2100 MHz, (20) 800 MHz, (28) 700 MHz, (3) 1800 MHz, (38) 2600 MHz, (40) 2300 MHz, (41) 2500 MHz, (7) 2600 MHz, (8) 900 MHz
Operating system
RutOS (OpenWrt based Linux OS)
Fans
No
LAN ports
4
LAN speed
(3) 10/100/1000Mbps + (1) 10/100/1000Mbps WAN
Max. power consumption [W]
10
Power via connector/terminal
9 .. 50V DC
Buttons
Reset
Operating temperature [°C]
-40 up to 75
Weight [g]
457
Width [mm]
115
Height [mm]
44
Depth [mm]
95
CPU
MediaTek, Dual-Core, 880 MHz, MIPS1004Kc
CPU frequency [MHz]
880
SIM slot
Yes
SIM slots quantity
2
USB
Yes
Default IP address
192.168.1.1
Internal storage [MB]
256
RAM [MB]
256
Default login and password
admin / admin01
GPS modul
Yes
