Teltonika RUTM11 Industrial 4G LTE Router
New
Your price incl. VAT (20.0%)
277.68 EUR
✅ In Stock < 10 Бр.
Planned Delivery Date by Courier to you 20-11-2024
Product description
Teltonika RUTM11 is an industrial LTE router from Teltonika, designed for applications that demand high data throughput and a robust network connection with zero tolerance for high latency and interruptions. The RUTM11 comes equipped with four Gigabit RJ45 ports, dual-band Wi-Fi, and dual SIM capabilities, enabling multiple failover scenarios. This router features LTE Cat 6, allowing it to achieve cellular speeds of up to 300 Mbps, which can be increased with carrier aggregation.
Package contents
- Router RUTM11
- 18 W PSU
- 2x Mobile antennas (swivel, SMA male)
- 2x Wi-Fi antennas (swivel, RP-SMA male)
- 1x GNSS antenna (adhesive, SMA male, 3 m cable)
- Ethernet cable (1.5 m)
- SIM Adapter kit
- QSG (Quick Start Guide)
- Packaging box
Download
Technical parameters
LAN ports
Power over Ethernet
9 .. 50V DC
Protection class
IP30
Supported VPN
GRE, IPSec, L2TP, OpenVPN, PPTP, Tinc, WireGuard, ZeroTier
Operating mode
3G/4G Router, Access Point, AP Router, Client, Client Router (wisp)
Management
SSH, Teltonika RMS, Web management
Wireless frequency
2.4 + 5 GHz (dual band), 3G (GSM), 4G (GSM), LTE
WiFi standards
802.11a, 802.11ac, 802.11b/g, 802.11n
Transmission speed - 5GHz [Mb/s]
866
Transmission speed - 2.4GHz [Mb/s]
300
Security
WPA, WPA2, WPA3
2.4GHz MIMO
2 x 2
5GHz MIMO
2 x 2
Detachable antennas
4
RF connectors
(3) SMA female, (2) RSMA female
Purpose
Indoor
Integrated 4G/LTE radio part
Yes
Power type
4-pin automotive, PoE
4G/LTE bands support
(1) 2100 MHz, (20) 800 MHz, (3) 1800 MHz, (38) 2600 MHz, (40) 2300 MHz, (41) 2500 MHz, (7) 2600 MHz, (8) 900 MHz
Operating system
RutOS (OpenWrt based Linux OS)
LAN ports
4
LAN speed
(3) 10/100/1000Mbps + (1) 10/100/1000Mbps WAN
Max. power consumption [W]
12,3
Power via connector/terminal
9 .. 50V DC
Buttons
Reset
Operating temperature [°C]
-40 up to 75
Weight [g]
460
Width [mm]
115
Height [mm]
44
Depth [mm]
95
CPU
MediaTek, Dual-Core, 880 MHz, MIPS1004Kc
CPU frequency [MHz]
880
SIM slot
Yes
SIM slots quantity
2
USB
Yes
IPv6 support
Yes
Default IP address
192.168.1.1
Internal storage [MB]
256
RAM [MB]
256
Default login and password
admin / admin01
GPS modul
Yes
