TP-Link EX520 - AX3000 Dual Band Wi-Fi 6 Router
Your price incl. VAT (20.0%)
71.64 EUR


Product description
You can set up your device and network in minutes, whether you prefer the powerful Aginet app or the intuitive web interface. The Aginet app allows you to manage your network from a smartphone or tablet.

Key features
- Dual-Band WiFi 6: Speeds up to 3000 Mbps — up to 2402 Mbps on 5 GHz and up to 574 Mbps on 2.4 GHz.
- Boosted Coverage: Four high-performance antennas and Beamforming technology combine to extend strong and reliable WiFi.
- More Connections: OFDMA and MU-MIMO technologies increase capacity and enable simultaneous transmission to more devices.
- EasyMesh: Create a smart mesh network with seamless coverage and greater flexibility based on standard mesh technology.
- Enhanced Security: WPA3 encryption, Multi-SSID, and Parental Controls provide personalized and safer online experience.
- Gigabit Wired Connections: 1x GE WAN port and 4x GE LAN ports provide fast and flexible internet access.
- Easy Setup: Set up your network in minutes with the powerful Aginet app.
- Remote Management: TAUC (TP-Link Aginet Unified Cloud), and TR-069, TR-098, TR-181, TR-111, TR-143 protocols are supported.

Package contents
- Device
- Power Adapter
- RJ45 Ethernet Cable
- Quick Installation Guide
Download
Technical parameters
LAN ports
WAN speed
(1) 10/100/1000Mbps
Maximum modulation
1024 QAM
Technology and conveniences
EasyMesh compatible
Operating mode
Access Point, AP Router
Wireless frequency
2.4 + 5 GHz (dual band)
WiFi standards
802.11a, 802.11ac, 802.11ax, 802.11b/g, 802.11n
MU-MIMO
Yes
Transmission speed - 5GHz [Mb/s]
2402
Transmission speed - 2.4GHz [Mb/s]
574
Tx power 2.4GHz [dBm]
23
Tx power 5GHz [dBm]
30
Security
WPA, WPA2, WPA3
2.4GHz MIMO
2 x 2
5GHz MIMO
2 x 2
Type of antenna
Fixed
Fixed antennas
4
Purpose
Indoor
LAN ports
5
LAN speed
(4) 10/100/1000Mbps
Gigabit LAN
Yes
Max. power consumption [W]
18
Power via connector/terminal
12V / 1,5A
Buttons
Reset, WPS, power, WiFi
Operating temperature [°C]
0 up to 40
Width [mm]
260
Height [mm]
42
Depth [mm]
135
IPv6 support
Yes
Default IP address
192.168.0.1
Default login and password
admin / admin
