MikroTik RouterBOARD RB4011iGS+5HacQ2HnD-IN

MikroTik RouterBOARD RB4011iGS+5HacQ2HnD-IN
Your price incl. VAT (20.0%)
249.50 EUR
✅ In Stock 10+ Бр.
Delivery Planned Delivery Date by Courier to you 20-11-2024
MikroTik
Manufacturer
Product number
RB4011iGS+5HacQ2HnD-IN
Product Code
RL006.056
Warranty
24 months

Product description

The RB4011 uses the amazingly powerful quad core cortex A15 chip from annapurna labs, an amazon company, same as in your grade rb1100AHx4 unit. The CPU supports IPsec hardware acceleration, there is 1GB of RAM, so this device will easily handle any task you have configured RouterOS to perform. All of this power, in a compact and professional looking solid metal enclosure in matte black. The router includes two rackmount ears, that will securely fasten the unit in standard 1U rack space.

RB4011iGS+RM

Equipment

The RB4011 is equipped with 10x GLAN, one SFP+ port and a power connector on the back side of the router. The first Gigabit port supports passive PoE, 10th port supports PoE-Out which is using to power another device with the same voltage as the RB4011.

Compared to the rack version, this version has 4 fixed omnidirectional antennas with a 3dBi gain and 2 built-in radio parts with1733 Mbps (5GHz) and 300 Mbps (2.4GHz).

RB4011iGS+RM

Package contains

  • Device
  • Power adapter 24V / 2.5A

Articles and reviews

Download

http://www.mikrotik.com/download
Download Firmware (RouterOS / SwOS)
https://download.discomp.cz/MikroTik/CE/ID015_2_RB4011iGS_5HacQ2HnD_IN_DOC_220733.pdf
Download CE
https://download.discomp.cz/MikroTik/Datasheets/RB4011-IN_180957.pdf
Download Datasheet
https://help.mikrotik.com/docs/display/QG
Download Quick Guide

Technical parameters

LAN ports
Power over Ethernet
18 .. 57V DC
Tx power [dBm]
33
Design
Desktop
Wireless frequency
2.4 + 5 GHz (dual band)
WiFi standards
802.11ac, 802.11b/g, 802.11a, 802.11n
Transmission speed - 5GHz [Mb/s]
1733
Transmission speed - 2.4GHz [Mb/s]
300
2.4GHz MIMO
2 x 2
5GHz MIMO
4 x 4
Type of antenna
Fixed
Antenna gain [dBi]
3
Power type
DC connector, PoE
Operating system
RouterOS - L5
LAN ports
10
LAN speed
(10) 10/100/1000Mbps
Gigabit LAN
Yes
PoE type
PoE-Out + PoE-In
SFP cages
1 (podpora 1G/10G)
SFP+ cages
1 (podpora 1G/10G)
Optical interfaces
(1) 1/10Gbps
PoE Out ports
1
Max. power consumption [W]
18
Power via connector/terminal
12 .. 57V DC
Operating temperature [°C]
-40 up to 45
Width [mm]
228
Height [mm]
30
Depth [mm]
120
CPU
AL21400
CPU frequency [MHz]
1400
CPU cores
4
Default IP address
192.168.88.1
Internal storage [MB]
512
RAM [MB]
1024
Default login and password
admin / -
