Technical parameters
LAN ports
Jumbo frame [Bytes]
10000
Design
Rackmount
Packet forwarding rate [Mpps]
83.33
Switchning capacity [Gbps]
56
MAC address table
8000
Web management
Yes
Management
SSH, Teltonika RMS, Web management
Features
L2+, QoS, VLAN
Power type
Mains power (230V)
Fans
No
LAN ports
24
LAN speed
(24) 10/100/1000Mbps
Max. LAN ports speed
1G
PoE type
PoE-Out (only)
SFP cages
4
Optical interfaces
(4) 1000Mbps
PoE-Out standards
802.3af, 802.3at
PoE Out ports
12
PoE budget [W]
300
Max. power consumption [W]
25
Chassis design
Metal
Power via connector/terminal
100-240 V AC~50/60 Hz
Buttons
Reset
Operating temperature [°C]
0 up to 50
Depth [mm]
234
Width [mm]
483
Height [mm]
44
Default IP address
192.168.1.2
Default login and password
admin / (preset password, see label/engraving)
