Teltonika SWM282 Industrial Managed Switch, 24x PoE GLAN, 4x SFP
Your price incl. VAT (20.0%)
308.99 EUR
Ordered for stock
Planned Delivery Date by Courier to you 01-10-2025
You have a choice of 3 variants
Product description
The SWM282 is a high-capacity L2 managed switch with enhanced L3 capabilities, built to simplify network control while delivering power and connectivity at scale. It features 24 PoE+ ports, supplying up to 30 W per port with a total power budget of 300 W, and 4 SFP ports. With support for PROFINET and other industrial protocols, this 24-port switch is an ideal choice for enterprise networks and IoT solutions.
FREE 2 years of RMS Management!
Key features
- PoE+: Deliver power and data through 24 PoE+ ports with up to 30W per port
- L2+: Advanced routing protocols and VLAN segmentation
- Cloud-enabled: Shipped with 2 years of RMS Management
- Protocols: Profinet, MRP, and EtherNet/IP for mixed industrial environments
Package contents
- Device
- QSG (Quick Start Guide)
Download
Technical parameters
LAN ports
Switchning capacity [Gbps]
56
Design
Rackmount
MAC address table
8000
Jumbo frame [Bytes]
10000
Packet forwarding rate [Mpps]
83.33
Web management
Yes
Management
Web management, SSH, Teltonika RMS
Features
VLAN, QoS, L2+
Power type
Mains power (230V)
Operating system
TSWOS (OpenWrt based Linux OS)
Fans
No
LAN ports
24
LAN speed
(24) 10/100/1000Mbps
Max. LAN ports speed
1G
PoE type
PoE-Out (only)
SFP cages
4
Optical interfaces
(4) 1000Mbps
PoE-Out standards
802.3af, 802.3at
PoE Out ports
24
PoE budget [W]
300
Max. power consumption [W]
330
Chassis design
Metal
Power via connector/terminal
100-240 V AC~50/60 Hz
Buttons
Reset
Operating temperature [°C]
0 up to 50
Weight [g]
2291
Height [mm]
44
Width [mm]
483
Depth [mm]
234
Default IP address
192.168.1.2
Default login and password
admin / (preset password, see label/engraving)
