Описание на продукт
Това е автоматичен превод. Оригиналния текст може да видите тукDS-P7001-01 is a GPON OLT unit with one GPON port supporting up to 128 clients (ONT units) with physical links reaching distances of up to 60 km. It features 1x SFP+ and 1x 2.5 Gigabit Ethernet as uplink, 1 Gigabit Ethernet for management only and RJ45 console port. For flexibility of your deployment, the OLT supports both DC 12V/2,5A and 802.3at PoE power supplies
Centralized Management via DPMS
Centralized management is done through the DeltaStream PON Management System (DPMS). Easy maintenance and centralized management will make your life much easier. Configure and update all your devices at once using DeltaStream PON Management System (DPMS), SNMP, CLI, or the web-based user interface.
Package Contents
- Device
- Power adapter
- 19" rack mounts
Свали
Технически параметри
LAN ports
Transfer type
GPON
LAN ports
1
LAN speed
(1) 100/1000/2500Mbps
SFP+ cages
1
PON SFP cages
1
Optical interfaces
(1) 10Gbps
Max. power consumption [W]
17
Serial port
RJ45
Power via connector/terminal
12V / 2,5A
Buttons
Reset
Operating temperature [°C]
0 up to 50
Depth [mm]
140
Width [mm]
294
Height [mm]
44
