Wireless frequency

2.4 GHz, LTE

WiFi standards

802.11b/g, 802.11n

Transmission speed - 2.4GHz [Mb/s]

150

Tx power 2.4GHz [dBm]

23

Security

WEP, WPA, WPA2, WPA3

2.4GHz MIMO

1 x 1 SISO

Type of antenna

Detachable

RF connectors

(1) RSMA female, (2) SMA female

Antenna gain [dBi]

5, 4

Integrated 4G/LTE radio part

Yes

Power type

DC connector

4G/LTE bands support

(1) 2100 MHz, (20) 800 MHz, (28) 700 MHz, (3) 1800 MHz, (32) 1500 MHz, (38) 2600 MHz, (39) 1900 MHz, (40) 2300 MHz, (41) 2500 MHz, (42) 3500 MHz, (43) 3700 MHz, (5) 850 MHz, (7) 2600 MHz, (8) 900 MHz

Operating system

RutOS (OpenWrt based Linux OS)

LAN ports

2

LAN speed

(2) 10/100Mbps (1x LAN/WAN)

Max. power consumption [W]

6,5

Power via connector/terminal

9 .. 30V DC

Buttons

Reset

Operating temperature [°C]

-40 up to 75

Weight [g]

130

Width [mm]

83

Height [mm]

25

Depth [mm]

74

SIM slot

Yes

SIM slots quantity

1

IPv6 support

Yes

Default IP address

192.168.1.1
