Ubiquiti UDW - UniFi Dream Wall
Planned Delivery Date by Courier to you 20-11-2024
Product description
Dream Wall is another in the range of UniFi All-in-one devices. It contains a gateway with a firewall, Wi-Fi 6 access point, NVR and a switch with PoE function. The unit provides a wide range of network connectivity options. It offers the option of connecting via a 10Gbps SFP+ port or a 2.5Gbps Ethernet port. For connecting other devices in the LAN, it offers a 10Gbps SFP+ port together with 17 Ethernet 1Gbps ports, of which 12 have PoE functionality (4x POE++, 4x POE+ and 4x POE). From the factory, the device is equipped with one hot-swap source with a power of 550W, and a second position is available for redundancy. The maximum consumption of the device is 532W including connected powered devices.
The radio part supports the latest WiFi 6 (802.11ax) standard, is backward compatible with older standards and has MIMO 2x2 (2.4 Ghz) and 4x4 (5 GHz) with a maximum modulation speed 300 + 2400 Mbps.
All important information about the device and the network can be accessed immediately thanks to the integrated display with a diagonal of 4.7". The pre-installed 512GB microSD card is used for storing camera recordings, and the device also has own SSD disk with a capacity of 128GB.
Supported UniFi services
- UniFi Network Controller
- UniFi Protect
- UniFi Access
- UniFi Talk
- UniFi Connect
Advantages of the UniFi solution
- Zero Handoff Roaming - uninterrupted transition between individual APs
- Wireless uplink (suitable where it is impossible to get a data cable)
- Up to 4 SSIDs
- Detailed traffic statistics
- Guest network
- Load balance - maintaining an even load / switching clients
- Speed limiting for each SSID
Package contents
- Device with pre-installed 512GB microSD card
- Screws and dowels
- Drilling template
- Wall mount
- Power cord
