Ubiquiti UDW - UniFi Dream Wall

Ubiquiti UDW - UniFi Dream Wall
Your price incl. VAT (20.0%)
1,126.02 EUR
✅ In Stock 10+ Бр.
Delivery Planned Delivery Date by Courier to you 29-01-2025
Ubiquiti Networks
Manufacturer
Product number
UDW
Product Code
RL025.304
Warranty
24 months

Product description

Dream Wall is another in the range of UniFi All-in-one devices. It contains a gateway with a firewall, Wi-Fi 6 access point, NVR and a switch with PoE function. The unit provides a wide range of network connectivity options. It offers the option of connecting via a 10Gbps SFP+ port or a 2.5Gbps Ethernet port. For connecting other devices in the LAN, it offers a 10Gbps SFP+ port together with 17 Ethernet 1Gbps ports, of which 12 have PoE functionality (4x POE++, 4x POE+ and 4x POE). From the factory, the device is equipped with one hot-swap source with a power of 550W, and a second position is available for redundancy. The maximum consumption of the device is 532W including connected powered devices.

The radio part supports the latest WiFi 6 (802.11ax) standard, is backward compatible with older standards and has MIMO 2x2 (2.4 Ghz) and 4x4 (5 GHz) with a maximum modulation speed 300 + 2400 Mbps.

All important information about the device and the network can be accessed immediately thanks to the integrated display with a diagonal of 4.7". The pre-installed 512GB microSD card is used for storing camera recordings, and the device also has own SSD disk with a capacity of 128GB.

Supported UniFi services

  • UniFi Network Controller
  • UniFi Protect
  • UniFi Access
  • UniFi Talk
  • UniFi Connect

Advantages of the UniFi solution

  • Zero Handoff Roaming - uninterrupted transition between individual APs
  • Wireless uplink (suitable where it is impossible to get a data cable)
  • Up to 4 SSIDs
  • Detailed traffic statistics
  • Guest network
  • Load balance - maintaining an even load / switching clients
  • Speed limiting for each SSID
Ubiquiti UDW

Package contents

  • Device with pre-installed 512GB microSD card
  • Screws and dowels
  • Drilling template
  • Wall mount
  • Power cord

Download

https://download.discomp.cz/Ubiquiti/Datasheets/udw_ds.pdf
Download Datasheet
https://download.discomp.cz/Ubiquiti/QSG/udw.pdf
Download Quick installation guide
