Ubiquiti UVC-G5-Dome-Ultra, UniFi Video Camera G5 Dome Ultra, white
Your price incl. VAT (20.0%)
89.47 EUR
❌ The item is not available. There is no option to order.
No confirmed delivery date
Manufacturer
Product number
UVC-G5-Dome-Ultra
Product Code
RL026.856
Warranty
24 months
You have a choice of 2 variants
45.74 EUR excl. VAT
45.95 EUR excl. VAT
45.95 EUR excl. VAT
Ubiquiti UACC-G5-Dome-Ultra-FM-W, flush mount for UVC-G5-DOMEUACC-G5-Dome-Ultra-FM-W
35.61 EUR excl. VAT
Product description
UVC-G5-Dome-Ultra is the 5th generation camera from the UniFi Video series. It has a 1/2.4" CMOS sensor with 4MP resolution (2688 x 1512 px, 16:9) @ 30 FPS. The fixed lens has a viewing angle of 102.4° horizontally, 54.9° vertically and 120.6° diagonally. The camera is equipped with (1) 10/100Mbps Ethernet port through which the camera is powered using POE 802.3af or passive POE with input voltage 37 - 57 V DC. For night mode, the camera is equipped with an IR illuminator with a range of 20 m. Maximum power consumption is only 4,2 W!
Package contents
- Camera
- (2) Metal holder
- Set of screws and nuts with metric thread
- Set of screws and dowels
- Drilling template
- Security pin
Download
Technical parameters
LAN ports
Power over Ethernet
802.3af, 37 .. 57V DC
Resolution
4MP
Camera class
UniFi Protect
Lens type
Fixed
Illumination
IR
Illumination range [m]
20
Purpose
Indoor
Max. resolution [pixels]
2688 x 1512
Viewing Angle [°]
102
Day/night mode
IR cut filter
Antivandal (Impact protection)
IK6
Power type
PoE
LAN speed
(1) 10/100Mbps
Max. power consumption [W]
4,2
Video compression
H.264
Buttons
Reset
Operating temperature [°C]
-20 up to 40
Weight [g]
175
Width [mm]
90
Height [mm]
68
Depth [mm]
63
Color
White
Image sensor ["]
1/2.4
Default IP address
Dynamic from DHCP
