Teltonika TRB160 4G LTE IoT Gateway
Your price incl. VAT (20.0%)
158.05 EUR
✅ In Stock < 10 Бр.
Planned Delivery Date by Courier to you 20-11-2024
Product description
The TRB160 is an ultra-small, lightweight, and energy-efficient IoT gateway equipped with mission-critical LTE Cat 6, Gigabit Ethernet, and a virtual network interface via USB Type-C for simultaneous powering and network data provision. This IoT gateway can reach cellular speeds of up to 300 Mbps with carrier aggregation in a broad range of applications and supports a wide range of industrial-grade protocols for M2M communication.
Package contents
- Device
- 9 W PSU
- (2) Mobile antenna (magnetic mount, SMA male, 3 m cable)
- USB Type-C cable (0.8 m)
- hex key
- Ethernet cable
- QSG (Quick Start Guide)
- Packaging box
Download
Technical parameters
LAN ports
Wireless frequency
3G (GSM), 4G (GSM), LTE
RF connectors
(2) SMA male
Power type
DC connector
Operating system
RutOS (OpenWrt based Linux OS)
LAN ports
1
LAN speed
(1) 10/100/1000Mbps
Max. power consumption [W]
3,3
Power via connector/terminal
9 .. 30V DC
Buttons
Reset
Operating temperature [°C]
-40 up to 75
Weight [g]
172
Depth [mm]
74
Width [mm]
83
Height [mm]
25
CPU
Qualcomm, 1.2 Ghz, ARM Cortex-A7
CPU frequency [MHz]
1200
SIM slots quantity
1
SIM slot
Yes
Internal storage [MB]
256
Default IP address
192.168.2.1
RAM [MB]
128
Default login and password
admin / (preset password, see label/engraving)
