Ubiquiti U6-LR - UniFi 6 Long-Range Access Point

Ubiquiti U6-LR - UniFi 6 Long-Range Access Point
Your price incl. VAT (20.0%)
190.01 EUR
✅ In Stock 90+ Бр.
Delivery Planned Delivery Date by Courier to you 02-10-2024
Ubiquiti Networks
Manufacturer
Product number
U6-LR
Product Code
RL009.032
Warranty
24 months

Product description

U6-LR is a high-performance Access Point leveraging advanced WiFi 6 technology to provide powerful wireless coverage to enterprise environments. It delivers an aggregate radio rate of up to 3.0 Gbps with 5 GHz (4x4 MU-MIMO and OFDMA) and 2.4 GHz 4x4 MIMO radios. The U6-LR seamlessly blends into any environment, and is capable of being mounted in indoor and semi-outdoor environments (IP54 rated).

Features

  • 1.3 GHz dual-core processor (now upgraded to support full-duplex 1 Gbps TCP/IP performance)
  • Four-stream high-efficiency Wi-Fi 6 technology
  • 5 GHz band 4x4 MU-MIMO and OFDMA with radio rate of 2.4 Gbps
  • 2.4 GHz band 4x4 MIMO with radio rate of 600 Mbps
  • Powered with 802.3at PoE
  • Managed by UniFi Network Controller version: 6.0.34 or higher

Unit central management

UniFi APs doesn't have own web GUI and you manage them via UniFi Controller, which you can download on UBNT websites here: http://www.ubnt.com. Or you can manage UAP devices using UniFi Cloud Key which has UniFi Controller preinstalled. Additional benefit is fact that UniFi Controller software is free of costs and includes advanced functions without limitations.

U6-LR

General advantages of UniFi products

  • Zero Handoff Roaming
  • Wireless uplink
  • Up to 8 SSID
  • Detailed traffic stats
  • Guest network
  • Load balance
  • Speed limitaions for each SSID

Package contains

  • Device
  • Ceiling / wall mount kit
  • Screws

Download

https://download.discomp.cz/ubiquiti/datasheets/u6-lr_ds.pdf
Download Datasheet
https://download.discomp.cz/ubiquiti/qsg/u6-longrange.pdf
Download Installation Guide

Technical parameters

LAN ports
Power over Ethernet
44 .. 57V DC, 802.3at
Protection class
IP54
Operating mode
Access Point
Wireless frequency
2.4 + 5 GHz (dual band)
WiFi standards
802.11a, 802.11b/g, 802.11n, 802.11ac, 802.11ax
MU-MIMO
Yes
Transmission speed - 5GHz [Mb/s]
2402
Transmission speed - 2.4GHz [Mb/s]
600
Tx power 2.4GHz [dBm]
26
Tx power 5GHz [dBm]
26
Security
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
2.4GHz MIMO
4 x 4
5GHz MIMO
4 x 4
Type of antenna
Built-in
Internal antennas
8
Purpose
Outdoor
Roaming
Yes
Antenna gain [dBi]
4, 5,5
LAN ports
1
LAN speed
(1) 10/100/1000Mbps
Gigabit LAN
Yes
PoE type
PoE-In (only)
Max. power consumption [W]
16,5
Buttons
Reset
Operating temperature [°C]
-30 up to 60
Weight [g]
800
Width [mm]
220
Height [mm]
48
Depth [mm]
220
IPv6 support
Transparent (bridge mode)
Default IP address
Dynamic from DHCP
Default login and password
ubnt / ubnt
