MikroTik RB924iR-2nD-BT5&BG770A&R11e-LR9G, KNOT LR9G kit
Your price incl. VAT (20.0%)
156.34 EUR
Ordered for stock
Planned Delivery Date by Courier to you 25-02-2026
Manufacturer
Product number
RB924iR-2nD-BT5&BG770A&R11e-LR9G
Product Code
RL030.345
Warranty
24 months
36.48 EUR excl. VAT
Product description
The MikroTik KNOT LR9G kit is a flexible industrial IoT gateway for asset tracking, remote monitoring, and efficient automation (Modbus and GPIO) with support for LoRa 915MHz, LTE Cat. M1 (LTE-M), LTE Cat. NB2, Bluetooth, Wi-Fi and GPS. It is equipped with (2) 10/100Mbps ports (1x PoE-In, 1x PoE-Out).
Key features
- LTE-M and NB2 with significantly lower operating costs compared to standard LTE data plans
- LoRa 915MHz, Bluetooth 5.2, Wi-Fi 4 and GPS
- RS485/Modbus with data transmission via MQTT or HTTP
- GPIO pins with monitoring capabilities
- Bluetooth beacon tracking
- (1) 10/100Mbps 802.3af/at PoE-In port and (1) 10/100Mbps 802.3af PoE-Out port
- Flexible power options - DC connector, Micro USB, or PoE
Package contents
- Device
- Power adapter 24V/1,2A
- Screws and wall plugs
- DIN rail mounting kit
- USB OTG cable
Download
Technical parameters
LAN ports
Power over Ethernet
802.3af, 802.3at, 18 .. 57V DC
Sensitivity [dBm]
-96
Design
On the wall, Desktop, DIN rail
Wireless frequency
2.4 GHz, LTE, Bluetooth, GNSS, 915 MHz
WiFi standards
802.11n, 802.11a, 802.11b/g
Transmission speed - 2.4GHz [Mb/s]
300
Tx power 2.4GHz [dBm]
22
2.4GHz MIMO
2 x 2
Type of antenna
Built-in, Detachable
Detachable antennas
3
Internal antennas
2
RF connectors
(3) SMA female
Antenna gain [dBi]
< 2
Power type
DC connector, PoE, USB (5V)
4G/LTE bands support
(1) 2100 MHz, (2) 1900 MHz, (3) 1800 MHz, (4) 1700 MHz, (8) 900 MHz, (20) 800 MHz, (5) 850 MHz, (12) 700 MHz, (17) 700 MHz, (25) 1900 MHz, (26) 850 MHz, (28) 700 MHz, (66) 1700 MHz, (13) 700 MHz, (18) 850 MHz, (19) 850 MHz, (27) 800 MHz
Operating system
RouterOS v7 - L4
Fans
No
LAN ports
2
LAN speed
(2) 10/100Mbps
PoE type
PoE-Out + PoE-In
PoE Out ports
1
Max. power consumption [W]
23
Chassis design
Plastic
Serial port
RS-485
Power via connector/terminal
12 .. 57V DC
Operating temperature [°C]
-40 up to 70
Height [mm]
26
Width [mm]
122
Depth [mm]
87
CPU
QCA9531
CPU frequency [MHz]
650
CPU cores
1
MiniPCI-e slots
1
SIM slots quantity
1
SIM slot
Yes
USB
Yes
Internal storage [MB]
128
Default IP address
192.168.88.1
Default login and password
admin / -
RAM [MB]
64
GPS modul
Yes
